| Research has proven that we learn much better when shown visual images, than any other form of learning. We can catch and understand, in a single glance, much more than if we read a description. In other words, it is much easier to understand complicated mechanisms like the ones we are about to show you, if we show you how they work visually. So without further a-do, here are some complicated mechanisms you may have always wondered about, in simple animation form! |
Radial Engines
Radial engines are used in aircraft having propeller connected to the shaft delivering power in order to produce thrust its basic mechanism is as follows
|
 |
|
Steam engine Principle
Steam engine once used in locomotives was based on the reciprocating principle as shown below. |
 |
|
| Sewing Machine |
 |
|
Maltese Cross Mechanism
this type of mechanism is used in clocks to power the second hand movement. |
 |
|
Manual Transmission Mechanism
The mechanism also called as “stick shift” is used in cars to change gears manually. |
 |
|
Constant Velocity Joint
This mechanism is used in the front wheel drive cars. |
 |
|
Torpedo-Boat destroyer System
This system is used to destroy fleet in naval military operations. |
 |
|
Rotary Engine
Also called as Wankel engine is a type of internal combustion engine has a unique design that converts pressure into rotating motion instead of reciprocating pistons. |
 |
|
|
 |
|
